Brilla NVR3216-P16 - 16CH POE Network Video recorder, 8 mp 2 SATA

Human and Vehicle detection supported

Key Features

 Support Ultra265/H.265/H.264 video formats

 16-channel input

 Plug & Play with 16 independent PoE network interfaces

 Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T

 Support HDMI and VGA simultaneous output

 Up to 8 Megapixels resolution recording

 2 SATA HDDs, up to 10TB for each HDD

 Support cloud upgrade

Specifications

Model NVR3216-P16

Video/Audio Input

IP Video Input 16-ch

Two-way Audio Input 1-ch, RCA

Network

Incoming Bandwidth 112Mbps

Outgoing Bandwidth 96Mbps

Remote Users 128

Protocols P2P, UPnP, NTP, DHCP, PPPoE

Video/Audio Output

1DATASHEET

VGA:1024X768@60,1280X720@60,1280X1024@60,1920X1080@50,1920X1080@60

HDMI/VGA Output

HDMI:4k(3840x2160@30),4k(3840x2160@60),1024X768@60,1280X720@60,1280X1024@60,1920X1080@50

,1920X1080@60

Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Audio Output 1-ch, RCA

Synchronous Playback 16-ch

Corridor Mode Screen 3/4/5/7/9/10/12/16

Decoding

Decoding format Ultra265/H.265/H.264

Live view/Playback 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Capability 1 x 4K@30, 2 x 4MP@30, 3 x 3MP@25, 4 x 1080P@30, 8 x 720P@30,16 x D1

Hard Disk

SATA 2 SATA interfaces

Capacity up to 10TB for each disk

External Interface

Network Interface 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface

USB Interface Front panel: 1 x USB2.0, Rear panel: 1 x USB2.0

Alarm In 4-ch

Alarm Out 1-ch

PoE

Interface 16 independent 100Mbps PoE network interfaces

Max 30W for single port

Max Power

Max 240W in total ( 15W for each )

Supported Standard IEEE 802.3af/at

General

220V AC

Power Supply

Power Consumption: ≤9 W( without HDD )

Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)

Dimensions(W×D×H) 380mm ×315mm × 49.1mm(15.0" × 12.4" ×1.9" )

Weight ( without HDD ) ≤2.4kg (5.29 lb)

The mobile app for this NVR is : Guard Viewer
